YP-AUDI-16 camera Add-On module for Audi with 4G MMI | Dynamic Parking Guide Line | Multiple video inputs
YP-AUDI-16 camera Add-On module for Audi with 4G MMI | Dynamic Parking Guide Line | Multiple video inputs

YP-AUDI-16 camera Add-On module for Audi with 4G MMI | Dynamic Parking Guide Line | Multiple video inputs

Brand: Yassi Pro

$599.99 * All prices are in CAD (Canadian Dollars)
INQUIRE ABOUT THIS PRODUCT

Notes: In-store only

Backup Camera
  • DESCRIPTION
  • Specifications
DESCRIPTION

AUDI 2015 and up 4G system

  •   External Device(DVD, DTV) is controlled by
  •   Multi Media Touch GUI
  •   It is possible to change the position of AV mode screen but the position of OEM screen is not changed.
  •   Improvement in Screen Display (User friendly interface)
  •   Able to change the mode by OEM button
  •   Power for rear camera is supplied(Activates when shifting into reverse)
  •   Dynamic PAS(Parking assistance system)+PDC,
  •   Moving parking line according movement of steering wheel

Compatibility

Brand

Model

Model years

System

From

To

Audi

A6

2015

–UP

MMI 4G

A7

2015

–UP

MMI 4G

A8

2015

–UP

MMI 4G



A4

2015

–UP

MMI 4G


Specifications

1. Car Compatibility

AUDI Cars in combination with MMI 4G



2. Components

   Interface* 1EA



3. MULTIMEDIA INTERFACE Input Specification

2 * A/V Input (Video External Input).

1 * CVBS(Rear Camera) input

1 * CVBS(Front Camera) input

1 * Analog RGB input (Navigation)

1 * LCD input (Car System input)



4. MULTIMEDIA INTERFACE Output Specification

1 * LCD Output



5. Power Specification

Input Power : 8VDC ~ 18VDC

Consumed Power : 5WATT



6. Switch input mode

- External display skip function : Able to control each video input by DIP switch

- Able to change input mode by momentary button

- Able to connect rear camera by either CAN or rear lamp cable
